МБ AMD B650 SAM5 MATX/TUF Gaming B650M-E ASUS WIFI

Цена без НДС: €137.75

€166.68

Наличие товара

Товар доступен на складе у поставщика

5-7 дней

>10 шт.

€166.68

Информация

Описание продукта: ASUS TUF GAMING B650M-E WIFI - motherboard - micro ATX - Socket AM5 - AMD B650
Тип продукта: Motherboard - micro ATX
Chipset Type: AMD B650
Processor Socket: 1 x Socket AM5
Compatible Processors: (supports Ryzen 7000 Series)
Max RAM Size: 192 GB
RAM Supported: 4 DIMM slots - DDR5, non-ECC, on-die ECC, unbuffered
Storage Ports: 4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports: 1 x USB-C 3.2 Gen 2 + 1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C 3.2 Gen 1 + 1 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.2

Параметры

Цвет:Melns

Гарантия

24 месяца, если иное не предусмотрено законом.

МБ AMD B650 SAM5 MATX/TUF Gaming B650M-E ASUS WIFI

€166.68

Генеральный

Тип продукта:

Motherboard - micro ATX

Chipset Type:

AMD B650

Processor Socket:

Socket AM5

Max Processors Qty:

Compatible Processors:

(supports Ryzen 7000 Series)

Supported RAM

Max Size:

192 GB

Технология:

DDR5

Bus Clock:

4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz (O.C.), 5600 MHz (O.C.), 5800 MHz (O.C.), 6400 MHz (O.C.), 6200 MHz (O.C.), 6000 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.), 7600 MHz (O.C.)

Supported RAM Integrity Check:

Non-ECC, on-die ECC

Registered or Buffered:

Unbuffered

Особенности:

Dual channel memory architecture, AMD EXPO technology

Audio

Тип:

HD Audio (8-channel)

Соответствующие стандарты:

High Definition Audio, DTS Sound Unbound

LAN

Network Interfaces:

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.2

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 2 x PCIe 4.0 x1 2 x M.2 socket (2242/2260/2280 M.2 Key M slot)

Storage Interfaces:

SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10

RAID Features:

AMD RAID Xpert2 Technology

Interfaces:

1 x HDMI 2 x DisplayPort 1 x USB-C 3.2 Gen 2 1 x USB 3.2 Gen 2 4 x USB 2.0 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x audio line-out - mini-jack 1 x audio line-in - mini-jack 1 x microphone - mini-jack

Internal Interfaces:

4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C 3.2 Gen 1 - header 1 x audio - header 1 x serial - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector

Features

BIOS Type:

AMI

BIOS Features:

UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode

Sleep / Wake Up:

Wake on LAN (WOL), wake on PME

Hardware Features:

ASUS OptiMem II, TUF LANGuard, Preboot eXecution Environment (PXE), ASUS Aura Sync, ASUS DIGI+ VRM, ASUS EZ DIY, ASUS Overvoltage Protection, ASUS ProCool, ASUS Q-Design, ASUS SafeDIMM, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS TUF Protection, BIOS FlashBack button, BIOS FlashBack LED, ESD Guards, Lighting Control, M.2 heatsink, M.2 Q-Latch, pre-mounted I/O shield, Q-DIMM, Q-LED, Q-Slot, VRM heatsink design, CrashFree BIOS 3, 8+2 Phase Power Design, AMD Precision Boost Overdrive (PBO), TUF 5K black metallic capacitors

Разное

Включенные аксессуары:

ASUS Wi-Fi moving aerial, 2 x M.2 rubber package, 2 x M.2 screw package, TUF certification card

Кабели в комплекте:

2 x Serial ATA cable

Software Included:

Armoury Crate, ASUS AI Suite III, ASUS AURA Creator, ASUS Fan Xpert 2+, ASUS TUF GAMING CPU-Z, ASUS TurboV EVO Utility, MyAsus, Norton 360 for Gamers (60 days trial), PC Cleaner, WinRAR

Соответствующие стандарты:

DisplayPort 1.4

Ширина:

24.4 cm

Глубина:

24.4 cm
