MSI B550-A PRO Processor family AMD, Processor socket AM4, DDR4 DIMM, Memory slots 4, Supported hard disk drive interfaces SATA, M.2, Number of SATA connectors 6, Chipset AMD B550, ATX

Цена без НДС: €93.21

€112.78

Наличие товара

Товар доступен на складе у поставщика

8-12 дней

>10 шт.

€112.78

Информация

Описание продукта: MSI B550-A PRO - motherboard - ATX - Socket AM4 - AMD B550
Тип продукта: Motherboard - ATX
Chipset Type: AMD B550
Processor Socket: 1 x Socket AM4
Compatible Processors: Ryzen (supports 3rd Generation Ryzen and New Generation Ryzen with Radeon Graphics)
Max RAM Size: 128 GB
RAM Supported: 4 DIMM slots - DDR4, non-ECC, ECC (operate in non-ECC mode), unbuffered
Storage Ports: 6 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports: 1 x USB-C Gen 2 + 1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C Gen 1 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Max Allocated RAM Size: 2 GB
Audio: HD Audio (8-channel)
LAN: Gigabit Ethernet

Гарантия

24 месяца, если иное не предусмотрено законом.

MSI B550-A PRO Processor family AMD, Processor socket AM4, DDR4 DIMM, Memory slots 4, Supported hard disk drive interfaces SATA, M.2, Number of SATA connectors 6, Chipset AMD B550, ATX

€112.78

Генеральный

Тип продукта:

Motherboard - ATX

Chipset Type:

AMD B550

Processor Socket:

Socket AM4

Max Processors Qty:

Compatible Processors:

Ryzen (supports 3rd Generation Ryzen and New Generation Ryzen with Radeon Graphics)

Supported RAM

Max Size:

128 GB

Технология:

DDR4

Bus Clock:

2400 MHz, 1866 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 3200 MHz, 3066 MHz

Supported RAM Integrity Check:

Non-ECC, ECC (operate in non-ECC mode)

Registered or Buffered:

Unbuffered

Особенности:

Dual channel memory architecture, supported ECC modules operate in non-ECC mode, A-XMP support

Graphics

Max Allocated RAM Size:

2 GB

Audio

Тип:

HD Audio (8-channel)

Audio Codec:

Realtek ALC892

Соответствующие стандарты:

High Definition Audio

LAN

Network Controller:

Realtek RTL8111H

Network Interfaces:

Gigabit Ethernet

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x16 (x4 mode (auto turn-off if M.2 is occupied)) 2 x PCIe 3.0 x1

Storage Interfaces:

SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 PCIe 3.0 -connectors: 1 x M.2 - RAID 0 / RAID 1

Interfaces:

1 x LAN (Gigabit Ethernet) 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-out (side surround) - mini-jack 2 x USB 3.2 Gen 1 1 x USB 3.2 Gen 2 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x USB-C Gen2 1 x PS/2 keyboard / mouse 4 x USB 2.0 1 x HDMI 1 x DisplayPort

Internal Interfaces:

4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C Gen 1 - header 1 x audio - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector

Features

Hardware Features:

AMD CrossFireX technology support, Debug LED, Double ESD Protection, 2oz Copper PCB, M.2 Shield FROZR, MSI Core Boost, MSI PCIe Steel Slot, MSI Mystic Light Sync
