MB B660 S1700 MATX / PRIME B660M-A Wi-Fi D4 ASUS

Цена без НДС: €103.24

€124.92

Наличие товара

Товар доступен на складе у поставщика

8-12 дней

>10 шт.

€124.92

Информация

Описание продукта: ASUS PRIME B660M-A WIFI D4 - motherboard - micro ATX - LGA1700 Socket - B660
Тип продукта: Motherboard - micro ATX
Chipset Type: Intel B660
Processor Socket: 1 x LGA1700 Socket
Compatible Processors: (supports 12th Generation Intel Core / Pentium Gold / Celeron)
Max RAM Size: 128 GB
RAM Supported: 4 DIMM slots - DDR4, non-ECC, unbuffered
Storage Ports: 4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports: 2 x USB 3.2 Gen 2 + 4 x USB 2.0 + (1 x USB-C Gen 1 + 4 x USB 3.2 Gen 1 + 5 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2

Гарантия

24 месяца, если иное не предусмотрено законом.

MB B660 S1700 MATX / PRIME B660M-A Wi-Fi D4 ASUS

€124.92

Генеральный

Тип продукта:

Motherboard - micro ATX

Chipset Type:

Intel B660

Processor Socket:

LGA1700 Socket

Max Processors Qty:

Compatible Processors:

(supports 12th Generation Intel Core / Pentium Gold / Celeron)

Supported RAM

Max Size:

128 GB

Технология:

DDR4

Bus Clock:

2133 MHz, 2400 MHz, 2800 MHz, 2666 MHz, 2933 MHz, 3000 MHz, 3200 MHz, 3333 MHz (O.C.), 3400 MHz (O.C.), 3466 MHz (O.C.), 3600 MHz (O.C.), 3733 MHz (O.C.), 4000 MHz (O.C.), 4266 MHz (O.C.), 4400 MHz (O.C.), 4600 MHz (O.C.), 4800 MHz (O.C.), 5000 MHz (O.C.), 5333 MHz (O.C.)

Supported RAM Integrity Check:

Non-ECC

Registered or Buffered:

Unbuffered

Особенности:

Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)

Audio

Тип:

HD Audio (8-channel)

Audio Codec:

Realtek ALC897

Соответствующие стандарты:

High Definition Audio

LAN

Network Interfaces:

Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 1 x PCIe 3.0 x16 (x4 mode) 1 x PCIe 3.0 x16 (x1 mode)

Storage Interfaces:

SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 2 x M.2

RAID Features:

Intel Rapid Storage Technology

Interfaces:

2 x HDMI 1 x DisplayPort 1 x LAN (Gigabit Ethernet) 2 x USB 3.2 Gen 2 1 x PS/2 keyboard / mouse 4 x USB 2.0 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack

Internal Interfaces:

5 x USB 2.0 - header 4 x USB 3.2 Gen 1 - header 1 x USB-C Gen 1 - header 1 x audio - header 1 x serial - header 1 x parallel - header 1 x SPDIF out - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector

Features

BIOS Features:

UEFI BIOS, ASUS EZ Flash 3

Sleep / Wake Up:

Wake on LAN (WOL), wake on PME

Hardware Features:

Intel Turbo Boost Max Technology 3.0, Intel Turbo Boost Technology 2.0, ASUS OptiMem II, Intel Optane Memory Ready, LANGuard, jack retasking, audio jack detect technology, ASUS 5X Protection III, ASUS DIGI+ VRM, ASUS Enhanced DRAM Overcurrent Protection, ESD Guards, ASUS Overvoltage Protection, ASUS SafeSlot Core+, ASUS Stainless Steel Back I/O, ASUS Q-Design, Q-DIMM, Q-Slot, ASUS EZ DIY, ASUS ProCool, ASUS Aura Sync, Armoury Crate, ASUS TurboV EVO, ASUS EPU (Energy Processing Unit), ASUS Fan Xpert 2+, Preboot eXecution Environment (PXE)
