MSI PRO B840-P WIFI

Cena bez PVN: €127.33

€154.07

Preces pieejamība

Prece ir pieejama piegādātāja noliktavā

5-7 dienas

3 gab.

Dalīties:

€154.07

Pamatinformācija

Produkta apraksts: MSI PRO B840-P WIFI - motherboard - ATX - Socket AM5 - AMD B840
Produkta veids: Motherboard - ATX
Chipset Type: AMD B840
Processor Socket: 1 x Socket AM5
Compatible Processors: Ryzen (supports Ryzen 7000/8000/9000 Series)
Max RAM Size: 256 GB
RAM Supported: 4 DIMM slots - DDR5, on-die ECC, non-ECC, ECC, unbuffered
Storage Ports: 4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports: 1 x USB-C 3.2 Gen 1 + 1 x USB 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C 3.2 Gen 1 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4

Garantija

24 mēneši, ja likumā nav noteikts citādi.

MSI PRO B840-P WIFI

€154.07

Vispārējais

Produkta veids:

Motherboard - ATX

Chipset Type:

AMD B840

Processor Socket:

Socket AM5

Max Processors Qty:

Compatible Processors:

Ryzen (supports Ryzen 7000/8000/9000 Series)

Supported RAM

Max Size:

256 GB

Tehnoloģija:

DDR5

Bus Clock:

4000 MHz (O.C.), 3200 MHz (O.C.), 2800 MHz, 2400 MHz

Supported RAM Integrity Check:

On-die ECC, non-ECC, ECC

Registered or Buffered:

Unbuffered

Iespējas:

Dual channel memory architecture, AMD EXPO technology

Audio

Tips:

HD Audio (8-channel)

Atbilstības standarti:

High Definition Audio

LAN

Network Controller:

Realtek RTL8125D

Network Interfaces:

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 3 x PCIe 3.0 x16 (x1 mode) 1 x PCIe 3.0 x16 (x4 mode) 1 x M.2 socket (2260/2280 M.2 Key M slot) 1 x M.2 socket (2260/2280/22110 M.2 Key M slot)

Storage Interfaces:

SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 2 x M.2

Interfaces:

1 x LAN (2.5Gigabit Ethernet) 1 x HDMI 1 x USB-C 3.2 Gen 2 1 x USB 3.2 Gen 2 2 x USB 3.2 Gen 1 4 x USB 2.0 2 x aerial 1 x audio line-out - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack

Internal Interfaces:

USB-C 3.2 Gen 1 - header 2 x USB 3.2 Gen 1 - header 2 x USB 2.0 - header 1 x audio - header 1 x serial - header 1 x SPI - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector

Features

BIOS Type:

AMI

BIOS Features:

MSI ClickBIOS 5

Hardware Features:

EZ Debug LED, M.2 Shield FROZR, EZ PCie Clip II, lightning gen4 solution, Extended Heatsink Design, pre-mounted I/O shield, 7+2+1 Phase Power Design, MSI Core Boost
