MSI MAG Z790 TOMAHAWK MAX WIFI mātesplate

Cena bez PVN: €218.83

€264.78

Preces pieejamība

Prece ir pieejama piegādātāja noliktavā

3-4 dienas

>10 gab.

Dalīties:

€264.78

Pamatinformācija

Produkta apraksts: MSI MAG Z790 TOMAHAWK MAX WIFI - motherboard - ATX - LGA1700 Socket - Z790
Produkta veids: Motherboard - ATX
Chipset Type: Intel Z790 / Nuvoton NCT6687D-M
Processor Socket: 1 x LGA1700 Socket
Compatible Processors: (supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron)
Max RAM Size: 192 GB
RAM Supported: 4 DIMM slots - DDR5, non-ECC, unbuffered
Storage Ports: 8 x SATA-600 (RAID), 4 x M.2
USB / FireWire Ports: 1 x USB-C 3.2 Gen 2x2 + 1 x USB-C 3.2 Gen 2 + 4 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + (1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4

Garantija

24 mēneši, ja likumā nav noteikts citādi.

MSI MAG Z790 TOMAHAWK MAX WIFI mātesplate

€264.78

Vispārējais

Produkta veids:

Motherboard - ATX

Chipset Type:

Intel Z790 / Nuvoton NCT6687D-M

Processor Socket:

LGA1700 Socket

Max Processors Qty:

Compatible Processors:

(supports 12th/13th and 14th Generation Intel Core / Pentium Gold / Celeron)

Supported RAM

Max Size:

192 GB

Tehnoloģija:

DDR5

Bus Clock:

5800 MHz (O.C.), 6000 MHz (O.C.), 4800 MHz, 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 7000 MHz (O.C.), 6800 MHz (O.C.), 7200 MHz (O.C.), 5200 MHz, 5000 MHz, 5600 MHz, 5400 MHz, 7400 MHz (O.C.), 7600 MHz (O.C.), 7800 MHz (O.C.)

Supported RAM Integrity Check:

Non-ECC

Registered or Buffered:

Unbuffered

Iespējas:

Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) 3.0

Audio

Tips:

HD Audio (8-channel)

Audio Codec:

Realtek ALC4080

Atbilstības standarti:

High Definition Audio

LAN

Network Interfaces:

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax/be (Wi-Fi 7), Bluetooth 5.4

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x PCIe 4.0 x16 (x4 mode) 1 x PCIe 3.0 x1 2 x M.2 socket (2242/2260/2280 M.2 Key M slot) 1 x M.2 socket (2260/2280/22110 M.2 Key M slot) 1 x M.2 socket (2260/2280 M.2 Key M slot)

Storage Interfaces:

SATA-600 -connectors: 7 x 7pin SATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 2 x M.2 SATA-600 / PCIe 4.0 -connectors: 1 x M.2 PCIe 5.0 -connectors: 1 x M.2

Interfaces:

1 x HDMI 1 x DisplayPort 4 x USB 3.2 Gen 1 4 x USB 3.2 Gen 2 1 x USB-C 3.2 Gen 2 1 x USB-C 3.2 Gen2x2 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x audio line-in - mini-jack 1 x SPDIF out 2 x aerial 1 x LAN (2.5Gigabit Ethernet)

Internal Interfaces:

4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x USB-C 3.2 Gen 2 - header 1 x audio - header 1 x SPI - header

Power Connectors:

24-pin main power connector, 2 x 8-pin ATX12V connectors

Features

BIOS Features:

UEFI BIOS, MSI ClickBIOS 5, ACPI 6.4 support, SMBIOS 3.5 support

Hardware Monitoring:

Fan control, fan speed detection, temperature detection

Hardware Features:

Super Charger, Clear CMOS Button, Debug LED, 6 Layer PCB, MSI Mystic Light, MSI Steel Armor, 2oz Copper PCB, M.2 Shield FROZR, pre-mounted I/O shield, MSI Core Boost, Extended Heatsink Design, DIY Friendly Design, 16+1+1 Phase Power Design, MSI Audio Boost 5, Server-Grade Low-Loss PCB, Safe boot button, flash BIOS button, 90A Power Stage, Frozr AI Cooling
