Gigabyte B760M DS3H AX 1.3 M/B Processor family Intel, Processor socket LGA1700, DDR4 DIMM, Memory slots 4, Supported hard disk drive interfaces SATA, M.2, Number of SATA connectors 4, Chipset Intel B760 Express, Micro ATX

Cena bez PVN: €111.62

€135.06

Preces pieejamība

Prece ir pieejama piegādātāja noliktavā

8-12 dienas

>10 gab.

Dalīties:

€135.06

Pamatinformācija

Produkta apraksts: Gigabyte B760M DS3H AX - 1.X - motherboard - micro ATX - LGA1700 Socket - B760
Produkta veids: Motherboard - micro ATX
Chipset Type: Intel B760
Processor Socket: 1 x LGA1700 Socket
Compatible Processors: (supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Max RAM Size: 192 GB
RAM Supported: 4 DIMM slots - DDR5, ECC (operate in non-ECC mode), non-ECC
Storage Ports: 4 x SATA-600 (RAID), 2 x M.2
USB / FireWire Ports: 1 x USB-C 3.2 Gen 2 + 3 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth

Garantija

24 mēneši, ja likumā nav noteikts citādi.

Gigabyte B760M DS3H AX 1.3 M/B Processor family Intel, Processor socket LGA1700, DDR4 DIMM, Memory slots 4, Supported hard disk drive interfaces SATA, M.2, Number of SATA connectors 4, Chipset Intel B760 Express, Micro ATX

€135.06

Vispārējais

Produkta veids:

Motherboard - micro ATX

Chipset Type:

Intel B760

Processor Socket:

LGA1700 Socket

Max Processors Qty:

Compatible Processors:

(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)

Supported RAM

Max Size:

192 GB

Tehnoloģija:

DDR5

Bus Clock:

4800 MHz, 5000 MHz, 5200 MHz, 5400 MHz, 5600 MHz, 5800 MHz (O.C.), 6000 MHz (O.C.), 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.)

Supported RAM Integrity Check:

ECC (operate in non-ECC mode), non-ECC

Iespējas:

Dual channel memory architecture, Intel Extreme Memory Profiles (XMP), supported ECC modules operate in non-ECC mode

Audio

Tips:

HD Audio (8-channel)

Atbilstības standarti:

High Definition Audio

LAN

Network Interfaces:

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe 4.0 x16 2 x PCIe 3.0 x1 2 x M.2 socket (2280 M.2 Key M slot)

Storage Interfaces:

SATA-600 -connectors: 4 x 7pin Serial ATA PCIe 4.0 -connectors: 2 x M.2

Interfaces:

2 x DisplayPort 1 x HDMI 1 x USB-C 3.2 Gen 2 3 x USB 3.2 Gen 1 2 x USB 2.0 1 x audio line-out - mini-jack 1 x microphone - mini-jack 1 x audio line-in - mini-jack 1 x LAN (2.5Gigabit Ethernet) PS/2 keyboard / mouse 2 x aerial

Internal Interfaces:

4 x USB 2.0 - header 2 x USB 3.2 Gen 1 - header 1 x audio - header 1 x SPI - header 1 x SPDIF out - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector

Features

BIOS Type:

AMI

BIOS Features:

PnP 1.0a support, DMI 2.7 support, WfM 2.0 support, SMBIOS 2.7 support, ACPI 5.0 support

Hardware Monitoring:

Fan fail warning, fan control, chassis temperature

Hardware Features:

Q-Flash Plus, Q-Flash, 6+2+1 Phase Power Design, M.2 Thermal Guard, GIGABYTE Smart Fan 6, Solid Pin Power Connectors, Audio Noise Guard, RGB FUSION, MultiKey, DIY Friendly Design
