Mainboard GIGABYTE AMD B650 SAM5 ATX Memory DDR5 Memory slots 4 1xPCI-Express 16x 2xPCI-Express 2.0 16x 3xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 7xUSB 3.2 1xUSB-C 1xRJ45 3xAudio port B650AELITEAXV2

Cena bez PVN: €159.20

€192.63

Preces pieejamība

Prece ir pieejama piegādātāja noliktavā

5-7 dienas

8 gab.

Dalīties:

€192.63

Pamatinformācija

Produkta apraksts: Gigabyte B650 AORUS ELITE AX V2 - motherboard - ATX - Socket AM5 - AMD B650
Produkta veids: Motherboard - ATX
Chipset Type: AMD B650
Processor Socket: 1 x Socket AM5
Compatible Processors: (supports Ryzen 7000/8000 Series)
Max RAM Size: 192 GB
RAM Supported: 4 DIMM slots - DDR5, non-ECC, unbuffered
Storage Ports: 4 x SATA-600 (RAID), 3 x M.2
USB / FireWire Ports: 1 x USB-C 3.2 Gen 2 + 2 x USB 3.2 Gen 2 + 5 x USB 3.2 Gen 1 + 4 x USB 2.0 + (1 x USB-C 3.2 Gen 2x2 + 2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
Audio: HD Audio (8-channel)
LAN: 2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.3

Garantija

24 mēneši, ja likumā nav noteikts citādi.

Mainboard GIGABYTE AMD B650 SAM5 ATX Memory DDR5 Memory slots 4 1xPCI-Express 16x 2xPCI-Express 2.0 16x 3xM.2 1xHDMI 1xDisplayPort 4xUSB 2.0 7xUSB 3.2 1xUSB-C 1xRJ45 3xAudio port B650AELITEAXV2

€192.63

Vispārējais

Produkta veids:

Motherboard - ATX

Chipset Type:

AMD B650

Processor Socket:

Socket AM5

Max Processors Qty:

Compatible Processors:

(supports Ryzen 7000/8000 Series)

Supported RAM

Max Size:

192 GB

Tehnoloģija:

DDR5

Bus Clock:

6666 MHz (O.C.), 6600 MHz (O.C.), 6400 MHz (O.C.), 6200 MHz (O.C.), 6000 MHz (O.C.), 5600 MHz (O.C.), 5200 MHz, 4800 MHz, 4400 MHz, 6800 MHz (O.C.), 7000 MHz (O.C.), 7200 MHz (O.C.), 7600 MHz (O.C.), 7800 MHz (O.C.), 8000 MHz (O.C.)

Supported RAM Integrity Check:

Non-ECC

Registered or Buffered:

Unbuffered

Iespējas:

Dual channel memory architecture, AMD EXPO technology, Intel Extreme Memory Profiles (XMP)

Audio

Tips:

HD Audio (8-channel)

Atbilstības standarti:

High Definition Audio

LAN

Network Controller:

Realtek RTL8852CE

Network Interfaces:

2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.3

Expansion / Connectivity

Expansion Slots:

1 x CPU 4 x DIMM 288-pin 1 x PCIe x16 2 x PCIe 3.0 x16 (x1 mode) 3 x M.2 socket (2280/25110 M.2 Key M slot)

Storage Interfaces:

SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 10 PCIe 5.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 10

Interfaces:

1 x HDMI 1 x DisplayPort 1 x USB-C 3.2 Gen 2 2 x USB 3.2 Gen 2 5 x USB 3.2 Gen 1 4 x USB 2.0 2 x aerial 1 x LAN (2.5Gigabit Ethernet) 1 x audio line-in - mini-jack 1 x audio line-out - mini-jack 1 x microphone - mini-jack

Internal Interfaces:

1 x USB-C 3.2 Gen 2x2 - header 2 x USB 3.2 Gen 1 - header 4 x USB 2.0 - header 1 x audio - header 1 x SPI - header

Power Connectors:

24-pin main power connector, 8-pin ATX12V connector, 4-pin ATX12V connector

Features

BIOS Type:

AMI

BIOS Features:

UEFI BIOS, PnP 1.0a support, DMI 2.7 support, WfM 2.0 support, SMBIOS 2.7 support, ACPI 5.0 support

Hardware Monitoring:

System voltage, temperature detection, fan speed detection, water cooling flow rate, fan fail warning, fan control

Hardware Features:

Q-Flash Plus, Q-Flash, 12+2+2 Phase Power Design, M.2 Thermal Guard, PCIe EZ Latch, M.2 EZ Latch plus, GIGABYTE Smart Fan 6, 6 Layer PCB, 2oz Copper PCB, M.2 Thermal Guard Ext., pre-mounted I/O shield, RGB FUSION, MultiKey, DIY Friendly Design, Ultra Durable
